Products Details
Check Valve
Seat type valves. Allow free flow from Port A to Port B and offer leakage Free closure in opposite direction. Two standard mounting styles
1) Inline mounting CV*T
Free closure in opposite direction
Allow free flow from Port A to Port B
TECHNICAL SPECIFICATIONS
| 1 | Construction | Seat type. |
| 2 | Mounting | Inline or subplate mounting. |
| 3 | Interface | Factory standard. |
| 4 | Mounting Position | Optional. |
| 5 | Flow Direction | Free flow from A to B. |
| 6 | Operating Pressure | 315 bar. |
| 7 | Hydraulic Medium | Mineral oil. |
| 8 | Viscosity Range | 10 cSt to 380cSt. |
| 9 | Fluid Temperature Range | -20 °C to +70 °C. |
| 10 | Fluid cleanliness requirement | As per ISO code 16/13 or better. |
| 11 | Cracking Pressure Available | 0.5, 1.5, 3 or 5 bar. |
